- Model
- YTK5
Item specifics
- Connectivity:
- WiFi 2.4G, Bluetooth, AP Hotspot
- Setup Method:
- QR‑Code pairing
- Image Sensor:
- 3MP / 4MP CMOS Sensor
- Video Compression:
- H.264, H.265 High Profile
- IR Night Vision:
- 850nm IR‑LED, 8‑10m IR distance
- Pan‑Tilt Angle:
- Pan 0‑350°, Tilt 0‑60°
- Smart Function:
- Two‑way audio, motion detection, auto tracking, human figure detection, sound detection, siren alarm
- Protocol:
- ONVIF supported
- Mobile APP
- Tuya / Smart Life, support iOS & Android
- Application:
- Home security, retail shop, office, small project
Review
Description
parameter | specification | |
CPU | spec | T31 |
Lens parameters | resolving power | 2304*1296 (3MP) |
focal length | 4mm | |
Relative aperture (aperture) | F2.0 | |
FOV(Field of view angle) | 100.3° | |
night vision | Night vision distance | 8-10m |
IR-CUT | support | |
IR Light | 2 850nm infrared lamps | |
Wi-Fi | standard | IEEE 802.11b/g/n |
distance | 10~20M(No barrier) | |
speaker | Speaker function | support |
microphone | sensitivity | -36dB± 2dB |
Signal-to-noise ratio | ≥58dB | |
Storage method | Cloud storage | support |
TF card storage | Supports TF cards, up to 256GB | |
interface | Reset button | support |
Power interface | USB 5V | |
Wired network interface | / | |
ac adapter | output | DC 5V |
interface | Micro USB | |
authentication | CE、ROHS | |
parts | Expansion screw pack | support |
Warranty card, manual, bracket | support | |
routine | working temperature | -10°C~50°C |
Storage temperature | -20°C~60°C | |
Working humidity | less than 95%(No condensation) | |
Product size | 73*73*120mm | |
Other requirements | Installation method | Wall mounted buckle (lifting/wall mounting) |
Packaging List | Power adapter x 1 camera x 1 manual x 1 installation accessory package x 1 installation buckle x 1 |
